SatLab SL800 - LED Indicator Function

`
11
LED indicator function
Receiver has three LED lights, respectively; satellite light, power lights (red and green),
signal lights (red and greens).
LED Indicator
Description
Power light (Green)
Solid
Battery fully charged
Power light (Yellow)
Solid
Battery good
Power light (Red)
Solid
Battery > 6% charge
Flash
Battery <5% charge
Flash
Battery status indicator: Flashes 1 to 4 times per
minute according to power status
1: 0% to 25%
2: 25% to 50%
3: 50% to 75%
4: 75% to 100%
Signal light (Green)
Off
Static Mode
Solid
RTK Mode
Signal light (Red)
Slow
Flash
1, RTK mode: flash at differential data interval
2, Static mode: flash at the sampling interval
Flash
Static mode: Storage space is less than 10MB
Satellite (Green)
Flash
Acquiring satellites
Solid
Satellites locked
All three LED’s illuminated
Flash
Reset Motherboard, release power button
Table 2.2 Indicator Function Description
