5 Technical Specification
TRANSMISSION STANDARDS
DVB-T, MPEG-2,MPEG-4,H.264
SATELLITE INPUT/DEMODULATION
Connector Type
F Type Female
Input Frequency
46 to 862 MHz
Input impedance
75 ohms
Band width
6M/7M/8M
ANT Power
5V<150mA 12V/24V<300mA,
Demodulation Type
COFDM :QPSK,16QAM,64QAM
LCD FEATURES
LCD Type
TFT TRANSMISSIVE
Number of Dots
480(RGB) x272
Active area (WxH)
2
95.04x53.86 mm
AV output interface
Connector Type
3.5 mm Jack
Video Output
CVBS,
Audio output
Stereo Audio L/R output
AV input interface
Connector Type
3.5 mm Jack
Video input
CVBS,
Audio input
Stereo Audio L/R input
AUDIO/VIDEO PROCESSING
Video decompression
MPEG-2 MP@HL, MPEG-1 Decoding,
MPEG-4 ASP@L5 HD resolution,
H.264 MP&HP@L4,HW JPEG decoding
Resolving rate
PAL-25 frame@720*576,NTSC-30
frame@720*480,
Signal compatibility
Support conversion for different video formats
Video Format
4:3,16:9,By Pan & Scan and Letter Box conversion
Audio decompression
MPEG-1 Layer I/II ，MPEG-2 Layer I/II,
Audio output mode
Stereo, Mono,R/L
DATA SERVICE PORT
Connector
USB
Data protocol
USB2.0 interface
File management system
NTFS,FAT32,FAT16
file format
wma,mp3,mp4,avi,jpg,jpeg,bmp,img
MICROPROCESSOR
Microprocessor
Amlogic
Clock Frequency
180MHz
SDRAM Memory
512Mbit
Power SUPPLY
Li_Ion Battery
8.4V/3000mAh
Adapter
OUTPUT :DC12V/1.5A,
INTUPT :100-240VAC 50/60Hz
Power consumption
Max. 10W
PHYSICAL CHARACERSTICS
Size (W x D x H)
3
205x125x45(mm )
Net Weight
0.66KG
