Hotkeys are quick actions the user can take with a single click. e Falcon has multiple pages of Hotkeys
(7 buttons per page). ink of this as pages of apps on a smartphone. e whole set of Hotkeys (all
pages) is editable from the Hotkey menu and is part of the areas automatically updated when Guidance
Modes change. Satloc recommends setting the most used Hotkeys on the rst page and lesser used
Hotkeys on subsequent pages. Appendix C shows options of what can be shown in the Hotkeys Area.
Hotkeys Area
is area display various information, depending upon the mode selected. Dry display information only
displays when Falcon Pro is in ‘Dry Mode.’ When in Liquid mode, auto dispersal will appear. is area
is also for warnings and notications. When a function is in use, its box will turn green. For example,
when the arm is activated, the light will be green.
Information Area
Bottom Display Area
Various buttons will appear in the Bottom Display Area, depending on the functions used.
e Setup Button opens a concise page with common information and user settings.
ese buttons zoom in and out. Also, a user can use his/her ngers to zoom in and
out by pinching ngers in and out.
e plane will remain at the center of the map unless the user drags the map to see something o
screen. e recenter button will restore the aircra to the center.
is area shows multiple buttons with various functions at dierent times,
depending on the Guidance Mode and the current swathing state. For example,
what is shown on the Moving Map image on the previous page is dierent from
what is displayed to the le of this paragraph.
e menu button on the top le-hand side will take a user back to the moving map screen. e menu in
the bottom will lead a user to the main menu screen.
Menu Buttons
Expand and Collapse Menus
When these icons appear, the menu can expand and collapse.
At the le is a collapsible panel that contains user-selected information and buttons. is is editable
from the screen display and is part of the areas automatically updated when Guidance Modes change.
Selections that are buttons have a blue background and typically allow the user to make quick edits to
that information.
Left Display Area
