SATO CG408TT Quick Guide

4
English
When Top Cover is Opened (Cutter Type (Optional))
Paper holder
Cutter unit
Platen roller
Paper sensor
Paper holder slide lever
When Top Cover is Opened (Dispenser Type (Optional))
Paper holder
Backing paper discharge outlet
Dispenser paper sensor
Platen roller
Paper sensor
Paper holder slide lever
Dispenser unit
(When the dispenser unit is open)
CG408412E.indb4CG408412E.indb4 2008/12/1514:24:072008/12/1514:24:07

SATO CG408TT Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	104 mm
Memory	8MB Flash ROM, 16MB SDRAM
Print Speed	4 ips
Media Sensor	Reflective and Transmissive
Interface	USB, RS232C
Optional Interfaces	Ethernet
Media Type	Roll, Fanfold
Media Width	22 mm to 118 mm
Media Thickness	0.06 mm - 0.2 mm
Ribbon Width	40 mm to 110 mm
Power Supply	AC 100-240V, 50/60 Hz
