RFID User Guide 8 PN: 9001147D
CALIBRATION MENU SCREEN REFERENCE
MENU DESCRIPTION
Allows the selection of the label quantity to be used for calibration. A measurement will
occur for each label to create a ratio of variance in determining the nominal. A report will
be issued.
Use the printer’s operator panel to scroll and select the desired option.
Allows the determination of label length to be used for calibration purposes. Use the
printer’s operator panel to scroll and select the desired setting. The increments are in
millimeters.
Allows the determination of the maximum quantity of write attempts at a single position.
Use the printer’s operator panel to scroll and select the desired attempts.
Allows the initialization of calibration. Ensure the printer is loaded with the intended
media to be calibrated. Use the printer’s operator panel to scroll and select the desired
option.
Displays the status of the active calibration. The “P” value represents the location
currently being calibrated. The “Ap” value represents the power being applied at the
time.
The time required to complete calibration may vary depending on label size and protocol
type.
Displays at the completion of calibration and prompts for option selection. Select PRINT
to print a chart of results and FINISH to bypass.
Use the printer’s operator panel to scroll and select the desired option.
Allows for the printing of an additional label containing the calibration results. Use the
printer’s operator panel to scroll and select the desired option.
Allows the selection of the manner of determining the best write position. Selecting
AUTO will allow the printer to make the determination. Selecting MANUAL will allow the
user to determine. If desirable results are achieved from the default position, select
MANUAL to achieve optimal speed performance of printer operation.
Use the printer’s operator panel to scroll and select the desired option.
Displays only if MANUAL was selected for determining the best write position, allowing
for the offset distance to be established. Use the printer’s operator panel to scroll and
select the desired offset distance. The measurement increments are in millimeters.
Allows for the determination of the antenna’s reception power when calibrating.
CALIBRATING..
P:XXX AP:XX.XDBM
