Sauder 417714 - Page 17

Step Step 11
å
Fasten twenty-eight ANGLE BRACKETS (5G) to the
OUTER ENDS (A and C). Use twenty-eight BLACK 9/16"
LARGE HEAD SCREWS (1S).
å
NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the OUTER ENDS.
å
Fasten four PLINTHS (JJJ) to the OUTER ENDS (A and C).
Use eight BLACK 9/16" LARGE HEAD SCREWS (1S).
5G
A
C
5G
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
JJJ
JJJ
JJJ
JJJ
(28 used)
Use bottom holes
Use bottom holes
BLACK 9/16" LARGE HEAD SCREW
(36 used in this step)
1S
417714www.sauder.com/services
Page 17
