Step
å
Fasten the LEFT BOTTOM (J) to the INNER LEFT END (D2).
Tighten two TWIST-LOCK® FASTENERS.
å
Fasten the LEFT BOTTOM (J) to the LEFT UPRIGHT (F). Use two
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å
Fasten the CONNECTOR PLATE (14G) to the LEFT TOP (H2). Use
four BLACK 9/16" LARGE HEAD SCREWS (1S).
å
Push two CORD CLIPS (9P) into the holes in the LEFT TOP (H2).
å
NOTE: The CORD CLIPS are used to manage your cords.
Step 16
BLACK 9/16" LARGE HEAD SCREW
(4 used for the CONNECTOR PLATE)
1S
417714 www.sauder.com/servicesPage 22
J
D2
H2
F
Surface with
TWIST-LOCK®
FASTENERS
KEYBOARD
DRAWER ON LEFT
9P
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
14G
To Next Page
