Step Step 15
å
Fasten the LEFT MODESTY PANEL (L) to the LEFT UPRIGHT (F). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å
Insert the dowel end of four TWIST-LOCK® FASTENERS (7F) into the
large holes in the LEFT TOP (H2) and LEFT BACK (O).
å
NOTE: If you already pushed TWIST-LOCK® FASTENERS into the large
holes in the LEFT UPRIGHT (F), pull the FASTENERS back out of the
holes. Pull at the front and back edges, slowly working the FASTENERS
out of the holes.
å
Push the LEFT UPRIGHT (F) onto the TWIST-LOCK® FASTENERS (7F)
in the LEFT TOP (H2) and LEFT BACK (O). Tighten the
TWIST-LOCK® FASTENERS.
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
7F
417714www.sauder.com/services
Page 21
L
F
F
O
H2
L
These edges
should be even.
KEYBOARD
DRAWER ON LEFT
1
st
2
nd
