Step Step 14
417714 www.sauder.com/servicesPage 20
å
Insert two METAL PINS (1R) into the holes in the TOP (H2).
å
Fasten the INNER LEFT END (D2) to the LEFT TOP (H2).
Tighten two TWIST-LOCK® FASTENERS.
å
NOTE: Be sure the METAL PINS insert into the holes in
the INNER LEFT END (D2).
å
Fasten the INNER LEFT END (D2) to the SPACER (LLL).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å
Fasten the LEFT BACK (O) to the INNER LEFT END (D2).
Tighten two TWIST-LOCK® FASTENERS.
LLL
D2
O
H2
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
Now might be a
good time to refresh
your drink.
1R
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
To Next Page
