Step
å
Fasten the CORNER BRACKETS (31G) to the SIDE
SKIRTS (RR and SS). Use eight BLACK 9/16" LARGE
HEAD SCREWS (1S).
å
Fasten an ANGLE BRACKET (5G) to the LEFT
SIDE SKIRT (SS). Use a BLACK 9/16" LARGE
HEAD SCREW (1S).
å
NOTE: Be sure the edge of the ANGLE
BRACKET is even with the edge of the
LEFT SIDE SKIRT.
å
Fasten the LEFT SIDE SKIRT (SS) to
the LEFT BOTTOM (J). Use fi ve
BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 18
J
SS
SS
RR
31G
5G
BLACK 9/16" LARGE HEAD SCREW
(14 used in this step)
1S
These edges
should be even.
417714 www.sauder.com/servicesPage 24
KEYBOARD
DRAWER ON LEFT
To Next Page
