Step Step 19
å
Fasten eight ANGLE BRACKETS (5G) to the BACK
SKIRTS (TT and UU). Use eight BLACK 9/16" LARGE
HEAD SCREWS (1S).
å
NOTE: Be sure the ANGLE BRACKETS are even with the
edges of the BACK SKIRTS.
å
Fasten the LEFT BACK SKIRTS (UU) to the
INNER LEFT END (D2), LEFT BOTTOM (J),
and LEFT SIDE SKIRT (SS). Use
eight BLACK 9/16" LARGE
HEAD SCREWS (1S).
J
SS
D2
UU
UU
TT
TT
5G
5G
5G
UU
UU
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
(8 used)
417714www.sauder.com/services
Page 25
KEYBOARD
DRAWER ON LEFT
To Next Page
