Step
å
You may need someone's help in this step.
å
Carefully stand your unit upright.
å
Fasten the CONNECTOR PLATE on the LEFT TOP (H2) to
the RIGHT TOP (G2). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
å
Fasten the RIGHT LEG (R) to the RIGHT MODESTY
PANEL (K). Use two BLACK 1-1/8" PAN
HEAD SCREWS (9S).
Step 28
H2
G2
R
K
BLACK 1-1/8" PAN HEAD SCREW
(2 used in this step)
9S
BLACK 9/16" LARGE HEAD SCREW
(4 used for the CONNECTOR PLATE)
1S
Pro Tip: Lift with your
legs. And, you know,
your arms.
417714 www.sauder.com/servicesPage 34
KEYBOARD
DRAWER ON LEFT
To Next Page
