Step
å
Fasten the DOOR (P) to the INNER RIGHT END (B2). Use the
screws in the HINGES. See the next step for door adjustments.
å
Before fastening the DOOR to your unit, be sure the mounting
screw is against the stops as shown in the right diagram. If it isn't,
loosen the mounting screw to slide it against the stops. Then
tighten the mounting screw.
å
Peel a FELT DISC from the FELT DISC CARD (1M) and stick it on
the DOOR where it comes in contact with the RIGHT UPRIGHT (E).
å
Fasten a KNOB (42K) to the DOOR (P). Use a GOLD 1"
MACHINE SCREW (50S).
Step 30
P
42K
1M
1M
E
B2
Mounting
screw
Stop
Hinge
GOLD 1" MACHINE SCREW
(1 used for the KNOB)
50S
417714 www.sauder.com/servicesPage 36
KEYBOARD
DRAWER ON LEFT
To Next Page
