Sauder Carson Forge 416969 - Step 2: Install Hidden Cams and Dowels; Insert hidden cams and cam dowels

å
Push twelve HIDDEN CAMS (1F) into the UPRIGHTS (E
and F) and BOTTOMS (J). Then, insert the metal end of a
CAM DOWEL (2F) into each HIDDEN CAM.
Step 2
416969www.sauder.com/services
Pae 7
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
F
E
J
J
(12 used)
Arrow
1F
2F
Do not tihten the HIDDEN CAMS in this step.
