NRT405F901 manual Chapter 19 BACnet signals 44

Chapter 19 BACnet signals

Analogue inputs

Object name Object ID Description Unit Writeable

RC_Actual_R.NRTRoomTemp Analog input, 0 Room temperature °C No

RC_Actual_R.NRTAIChangeOver Analog input, 1 Change-over temperature °C No

RC_Actual_R.NRTAnaIn1 Analog input, 2 Value on analogue input 1 °C No

RC_Actual_R.NRTUAnaIn1 Analog input, 3 Value on universal analogue

input 1

V No

Not used in this model Analog input, 4 No

Analogue values

Object name Object ID Description Unit Writeable

RC_Actual_R.NRTUAnaOut1 Analog value, 0 Value on universal analogue

output 1

V No

RC_Actual_R.NRTUAnaOut2 Analog value, 1 Value on universal analogue

output 2

V No

RC_Actual_R.NRTSetPAdjustment Analog value, 2 Setpoint adjustment from

internal unit

°C No

RC_Actual_R.NRTPIDSetP Analog value, 3 Controller setpoint °C No

RC_Actual_R.NRTPIDOutput Analog value, 4 Controller output % No

RC_Actual_R.NRTHeatOutput Analog value, 5 Heating control % No

RC_Actual_R.NRTCoolOutput Analog value, 6 Cooling control % No

Not used in this model Analog value, 7-8 Yes

RC_Setp_R.NRTUnOccSetPHeat Analog value, 9 The room heating setpoint

when in unoccupied mode

°C Yes

RC_Setp_R.NRTUnOccSetPCool Analog value, 10 The room cooling setpoint

when in unoccupied mode

°C Yes

Not used in this model Analog value, 11-12 Yes

RC_Setp_R.NRTHeatOutputManual Analog value, 13 Manual value heating output % Yes

RC_Setp_R.NRTCoolOutputManual Analog value, 14 Manual value cooling output % Yes

RC_Setp_R.NRTRoomTempRemote Analog value,15 Remote control of room

temperature.

°C Yes
