NRT405F901 manual Chapter 19 BACnet signals 46
Object name Object ID Description Values Writeable
Not used in this model Binary value, 8 No
RC_Actual_L.NRTBypass Binary value, 9 Forces the unit into Bypass
mode. Reverts automatically
after Bypass time has elapsed
(FS=120 min)
ACTIVE/
INACTIVE
Yes
RC_Actual_L.NRTShutDown Binary Value, 10 Forces the unit into
Shutdown mode
ACTIVE/
INACTIVE
Yes
All binary values have normal polarity
Loop
Object name Object ID Description
Controller Loop, 0 The NRT controller
Multistate inputs
Object name Object ID Description Values Writeable
Not used in this model Multistate input, 0 No
RC_Actual_X.NRTUnitState Multistate input, 1 Current running
mode
1=Off
2=Unoccupied
3=Stand-by
4=Occupied
5=Bypass
No
RC_Actual_X.NRTControllerState Multistate input, 2 Current control
mode
1=Off
2=Heating
3=Cooling
No
RC_Actual_X.NRTFanSpeed Multistate input, 3 Current fan speed 1=Off
2=Fan speed 1
3=Fan speed 2
4=Fan speed 3
No
