2.3. REM-4000 (Pro Remote X2)
The following tables describe technical hardware features of the REM-4000 Pro Remote.
C
A
E
G
I
A
B
D
F
H
J
A
Microphone Front and rear panel Microphones for Voice
Commands.
IMPORTANT! Do not insert objects into the
microphone openings.
B
Touchscreen
Display
– Multi-colored LCD display for viewing and
controlling available Services.
– Touch and swipe operation.
C
Navigation (D-pad) – Standard up, down, left, and right arrows for on-
screen control.
– Dedicated page up and page down buttons.
– Press the Select button at the center of the
D-pad to select the highlighted item.
D
Channel Channel Up or Channel Down for the active service
(includes Last / Back).
E
Volume Increase or decrease volume of the active service
(includes Mute).
F
Voice
Commands
– Activate Services, Scenes, environmental
controls, and other functions.
– Press and hold, then wait for on-screen prompt,
speak commands clearly.
TIP: Say the phrase “Voice Commands” into the
remote to open a list of supported actions.
G
Service Control – Generic service buttons for control over AV
Services includes: Menu/Info/Guide/Exit/
Rewind/PlayPause/FastForward/Back.
– Function can change depending on Active
Service.
NOTE: Not all Services are aected by all buttons.
H
Ellipses Configurable by Savant Integrator.
I
Savant “S” Quick activation of Savant Home app for Apple TV
(also configurable by Savant Integrator).
J
Power
Button
Press/Release:
– Powers the Remote on. Savant Logo will
appear in 5 to 7 seconds.
– With the Remote powered on, the power button
can toggle the last used A/V service on or o
– Can be configured to require two presses to turn
last used A/V service o.
Press/Hold (5 sec): Powers Remote o.
Remote Base Status
LED
O: Not powered
Solid Green: Powered
Remote Base
Charges the battery when the Remote is set into
the Remote Base.
