SawStop CB53230 - Internal Assembly Parts List

SawStop 10” Industrial Cabinet Saw 85
No. Description Part No. Qty.
1
3HP, 1PH, 208-240V, 60Hz, TEFC Motor CB104 069
1
3HP, 3PH, 208-240V, 60Hz, TEFC Motor CB104 070
5HP, 1PH, 208-240V, 60Hz, TEFC Motor CB104 071
5HP, 3PH, 208-240V, 60Hz, TEFC Motor CB104 072
5HP, 3PH, 480V, 60Hz, TEFC Motor CB104 073
7.5HP, 3PH, 208-240V, 60Hz, TEFC Motor CB105 015
7.5HP, 3PH, 480V, 60Hz, TEFC Motor CB105 016
5HP, 3PH, 200V, 50-60Hz, TEFC Motor (Japan only) CB105 026
2 M12x1.75x110 Hex Head Bolt CB104 074 1
3 M12x1.75 Motor Positioning Bolt CB104 075 1
4 Motor Pulley CB104 076 1
5 M5x5x30 Key CB104 077 1
6 M6x1.8 Set Screws CB104 078 2
7 Tilt Lock Knob CB104 079 1
8 Front Trunnion Bracket CB104 080 1
9 Pin CB104 081 6
10 M10x1.5x55 Hex Head Limit Bolt CB104 082 3
11 M10x1.5 Nut CB104 083 4
12 Front Trunnion CB104 084 1
13 Rear Trunnion Bracket CB104 085 1
14 M10x1.5x45 Hex Head Bolt CB104 086 4
15 M10.2x18.5 Lock Washer CB104 087 13
16 M10x25x3 Washer CB104 088 8
17 Rear Trunnion CB104 089 1
18 Trunnion Brace CB104 090 1
19 M10x1.5x40 Socket Head Bolt CB104 091 9
20 Front Dust Shroud CB104 092 1
21 M6x1.0x16 Socket Head Screw CB104 093 2
22 Riving Knife CB104 094 1
23 Dust Shroud Door CB104 095 1
24 Pivot Pin CB104 096 1
25 M12 E-Clip CB104 097 2
26 Thumb Screw CB104 098 1
27 Dust Hose Coupling CB104 099 1
28 M6x1.0x15 Phillips Head Screw CB104 100 4
29 M6.3x13x2 Washer CB104 101 4
30 Bumper CB104 102 1
31 M6x1.0x12 Socket Head Screw CB104 103 7
32 V-Bracket CB104 104 1
33 M8x1.25x20 Socket Head Screw CB104 105 4
34 M8.2x15.4 Lock Washer CB104 106 12
Internal Assembly Parts List
