SBE SB-36 OPERATION MANUAL
FEP-511 5.6 MHz OSCILLATOR/UPPER AND LOWER LIMIT LIGHT PC BOARD
SYM
PART NUMBER
DESCRIPTION
Cl 8000-00010-162 Capacitor, Fixed, Mica, 30pF, 50V
C2 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C3 8000-00010-121 Capacitor, Fixed, Mica, 100pF, 50V
C4 8000-00010-059 Capacitor, Fixed, Mica, 250pF, 50V
C5 8000-00010-120 Capacitor, Fixed, Mica, 50pF, 50V
C5B 8000-00010-120 Capacitor, Fixed, Mica, 50pF, 50V
C6 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C7 8000-00010-120 Capacitor, Fixed, Mica, 50pF, 50V
C8 8000-00010-055 Capacitor, Fixed, Styrol, 500pF, 50V
C9 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C10 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C11 8000-00010-055 Capacitor, Fixed, Styrol, 500pF, 50V
C13A 8000-00010-164 Capacitor, Fixed, Mylar, 0.1µF, 50V
C13B 8000-00010-163 Capacitor, Fixed, Styrol, 1000pF, 50V
C14 8000-00010-155 Capacitor, Fixed, Styrol, 1500pF, 50V
C15 8000-00010-059 Capacitor, Fixed, Mica, 250pF, 50V
C16 8000-00010-165 Capacitor, Fixed, Mylar, 0.5µF, 50V
C17 8000-00010-165 Capacitor, Fixed, Mylar, 0.5µF, 50V
C18 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C19 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C20a 8000-00010-164 Capacitor, Fixed, Mylar, 0.1µF, 50V
C20b 8000-00010-163 Capacitor, Fixed, Styrol, 1000pF, 50V
C20d 8000-00010-122 Capacitor, Fixed, Mica, 100pF, 50V
C20e 8000-00010-164 Capacitor, Fixed, Mylar, 0.1µF, 50V
C003 8000-00010-169 Capacitor, Fixed, Electrolytic, 330µF, 16V
C004 8000-00010-174 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C005 8000-00010-174 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C006 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C007 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C008 8000-00010-17? Capacitor, Fixed, Ceramic, 0.005µF, 500V
C206 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C501 8000-00010-115 Capacitor, Fixed, Electrolytic, 47µF, 16V
C503 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16V
C503a 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C504a 8000-00010-122 Capacitor, Fixed, Mica, 1000pF, 50V
C504b 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C506 8000-00010-168 Capacitor, Fixed, Electrolytic, 100µF, 10V
D1 8000-00010-152 Diode, RD-5A
D2 8000-00010-152 Diode, RD-5A
L1 8000-00010-170 Coil
