SBE SB-36 OPERATION MANUAL
FEP-531 POWER SUPPLY PC BOARD
SYM
PART NUMBER DESCRIPTION
C504 8000-00010-177 Capacitor, Fixed, Electrolytic, 100µF, 250V
C505 8000-00010-178 Capacitor, Fixed, Electrolytic, 470µF, 16V
C506 8000-00010-179 Capacitor, Fixed, Electrolytic, 1000µF, 35V
C507 8000-00010-179 Capacitor, Fixed, Electrolytic, 1000µF, 35V
D50l 8000-00010-176 Diode, 10D-10
D502 8000-00010-176 Diode, 10D-10
D503 8000-00010-176 Diode, 10D-10
D504 8000-00010-176 Diode, 10D-10
D506 8000-00010-176 Diode, 10D-10
D507 8000-00010-176 Diode, 10D-10
D508 8000-00010-176 Diode, 10D-10
D509 8000-00010-176 Diode, 10D-10
D510 8000-00010-176 Diode, 10D-10
D511 8000-00010-176 Diode, 10D-10
D512 8000-00010-176 Diode, 10D-10
D513 8000-00010-021 Diode, 10D-1
D514 8000-00010-021 Diode, 10D-1
D515 8000-00010-021 Diode, 10D-l
D516 8000-00010-021 Diode, 10D-1
FEP-532 20V REGULATOR PC BOARD
SYM
PART NUMBER
DESCRIPTION
C511 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C512 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16V
C513 8000-00010-183 Capacitor, Fixed, Electrolytic, 220µF, 16V
D31 8000-00010-128 Diode, RD-16A
R512 8000-00010-180 Resistor, Fixed, 1Ω, 2W
TR45 8000-00010-002 Transistor, 2SC458
TR46 8000-00010-175 Transistor, 2SC491
TR47 8000-00010-002 Transistor, 2SC458
VR19 8000-00010-181 Resistor, Variable, 1kΩ

8000-00010-182 TR-46 Heat Sink

8000-00010-184 L Angle Bracket
