SBE SB-36 OPERATION MANUAL
SB-36 MAIN CHASSIS
SYM
PART NUMBER
DESCRIPTION
C25 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C35 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C45 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C55 8000-00010-213 Capacitor, Fixed, Ceramic, 0.002µF, 3kV
C65 8000-00010-189 Capacitor, Fixed, Ceramic, 0.01µF, 1.4kV
C71 8000-00010-210 Capacitor, Fixed, Ceramic, 300pF, 500V
C74 8000-00010-210 Capacitor, Fixed, Ceramic, 300pF, 500V
C75 8000-00010-211 Capacitor, Fixed, Ceramic, 470pF, 1.6kV
C85 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C674 8000-00010-209 Capacitor, Fixed, Ceramic, 0.002µF, 500V
C675 8000-00010-209 Capacitor, Fixed, Ceramic, 0.002µF, 500V
C695 8000-00010-212 Capacitor, Fixed, Ceramic, 150pF, 500V
C701 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C702 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C703 8000-00010-207 Capacitor, Fixed, Ceramic, 0.005µF, 500V
C710 8000-00010-212 Capacitor, Fixed, Ceramic, 150pF, 500V
C205 8000-00010-020 Diode, 1N60
L55 8000-00010-235 Choke
L75 8000-00010-234 Choke
L85 8000-00010-234 Choke
L205 8000-00010-230 Choke, Plate
L215 8000-00010-231 Coil, Tank
L225 8000-00010-232 Coil, Tank, 10 Meter
L305 8000-00010-233 Choke
L315 8000-00010-233 Choke
R15 8000-00010-228 Resistor, Fixed, 0.5Ω
R95 8000-00010-229 Resistor, Fixed, 5kΩ, 10 w
RL1 8000-00010-215 Relay, MH4
RL2 8000-00010-214 Relay, 4-Pole
S1 8000-00010-200 Switch, Mode
S2 8000-00010-202 Switch, Band
S3 8000-00010-201 Switch, 3-Position, Meter
S4 8000-00010-206 Switch, Noise Blanker
S5 8000-00010-203 Switch, AGC
S6 8000-00010-205 Switch, Push Button
S7 8000-00010-204 Switch, 2p-3T
S8 8000-00010-205 Switch, Push-Button
V5 8000-00010-092 Tube, 6KD6
V6 8000-00010-092 Tube, 6KD6
VC10 8000-00010-226 Capacitor, Variable
VC15 8000-00010-225 Capacitor, Variable, 10pF
