48
Section 6
WARNING
BATTERIES PRODUCE EXPLOSIVE GASES.
Charge the battery in a well ventilated space so
gases produced while charging can dissipate.
Charging rates between 3 and 50 amperes are satisfactory
if excessive gassing or spewing of electrolyte does not
occur or the battery does not feel excessively hot (over
125°F). If spewing or gassing occurs or the temperature
exceeds 125°F, the charging rate must be reduced or
temporarily stopped to permit cooling.
B. JUMP STARTING
1. The booster battery must be a 12 volt type. If a
vehicle is used for jump starting, it must have a
negative ground system.
2. When connecting the jumper cables, connect the
positive cable to the positive battery post, then
connect the negative cable to the negative battery
post.
6.8 DRIVE BELTS
All drive belts are spring-loaded and self-tensioning,
however after the first 2, 4, 8 and 10 hours of operation,
the belts should be checked for proper alignment and wear.
Thereafter, check the belts after every 40 hours of operation
or weekly, whichever occurs first.
- NOTE -
If you experience frequent belt wear or breakage,
see your authorized Scag service center for belt
adjustment.
WARNING
If the pump drive belt fails, steering control will be
lost which could result in serious injury or death.
Replace the pump drive belt as needed or every
400 hours / 2 years, whichever occurs first.
6.9 TIRES
Check the tire pressures after every 8 hours of operation
or daily.
Caster Wheels 20 PSI
Drive Wheels 12 PSI
6.10 BODY
CAUTION
Do not wash any portion of the equipment while it
is hot. Do not wash the engine; use compressed
air.
1. After each use, wash the machine. Use cold water
and automotive cleaners. Do not use pressure
cleaners.
2. Do not spray electrical components.
3. Repair damaged metal surfaces using Scag touch-
up paint (P/N 48521 - Scag Gold - aerosol can,
484540-01 - 0.6fl.oz. Scag Gold - bottle with brush,
or 486269 - Black Textured - aerosol can) available
from your authorized Scag dealer. Wax the machine
with an automotive paint wax for maximum paint
protection.
6.11 SPRAYER MAINTENANCE
A. CLEANING THE SPRAYER
WARNING
Swallowing or inhaling chemicals could cause
serious injury or death
Do not clean spray nozzles using your mouth or
blowing through the nozzles
Replace all worn or damaged sprayer nozzles
Ensure the nozzles are installed correctly..
1. Park the machine in a designated cleaning area with
a level surface.
