SCAC STS60-23BV - Page 63

57
R
Section 7
SPRAYER SYSTEM
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
486606
486549
486084-03
48136-04
486191
486552
486090
486083-07
486185
486187
486186
486188
486084-05
486081-03
486083-09
486112
463276
486453
486088-02
463275
486556-01
486155
486412
463267
486395
04201-13
04317-01
486190
486411
486905
48136-13
486860
Hose Reel Assy
Valve, Ball 1/2" NPT
Fitting, 90 Deg.1/2 - 14 NPT X 3/4" Hose
Hose Clamp
Hose, 3/4" EPDM ( Order by the inch)
Fitting, 3/4" O-ring
Pump, 12V Electric
Hose Barb, 1/2" NPT X 3/4" Hose
Strainer Head
Gasket
Screen
Bowl
Fitting, 90 Deg. 3/4 - 14 NPT x 3/4" Hose
Tee Fitting, 1/2 NPT
Hose Barb, 3/4 NPT x 3/4" Hose
Cap, Sprayer
Tank Assy, RH
Drain Plug, 3/4"
Fitting, 3/4" NPT
Tank Assy, LH
Fitting, Street Elbow 90 Deg. 1/2"
Fitting, Valve
Pressure Gauge
Valve Assy (Incl.
Mounting Bracket, Valve Assy
Bolt, 1/4 - 20 x 2.75 - Stainless Steel
Locknut, 1/4 - 20 Flg. Elastic Stop - Stainless Steel
Hose, 1/2" EPDM ( Order by the inch)
Fitting, 45 Degree 1/4 NPT
Fitting, Valve
Hose Clamp
Sprayer Gun
