Section 7
FUEL SYSTEM
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
428290
04201-16
04030-03
428473
463282
04241-02
*
48059-01
484347
484279-03
484333
486181
484243
484286
Mounting Bracket, Fuel Tank
Bolt, Hex Head 5/16 -16 x 3/4" - Stainless
Steel
Washer, Lock 5/16" - Stainless Steel
Mounting Bracket, Oil Reservoir
Fuel Tank Assy, (Incl. # 11,12,13,15,16)
Washer, Flat 5/16" x .375 x .875 x .084 -
Stainless Steel
Fuel Filter
Clamp, Fuel Hose
Hose, Vapor Recovery 1/4" (order by inch)
Tube, Fuel Tank Insert
Remote Vent w/ No Valve
Valve, Fuel Shutoff w/ Pickup Line
Fuel Gauge Assembly 11" (INCL. 17)
Fuel Cap, Tethered
15
16
17
18
19
482571
484285
484242
484343-01
48059-05
Bushing, 0.56 Viton
Grommet, Kelch
Seal, Fuel Gauge
Mender, 1x4 x 3/16 w/.02 Hole
Clamp, Fuel Hose 3/16" ID
* Order through Engine Manufacturer
