Section 7
SPRAYER PUMP
Ref.
No.
Part No. Description
1
2
3
4
5
6
*
486090
486901
486897
486898
486899
**486902
486900
Pump. 12v - 5 GPM
Screw Kit, Remco (all pumps)
Bypass, Upper Housing (5.3 GPM)
Valve Housing (5.3 GPM)
Lower Housing (5.3 GPM)
Pump Head Assembly (7 GPM -Optional Accessory)
Outlet Check Valve (5 GPM & 7 GPM)
* Not Shown
** Only available as an assembly for the optional 7GPM pump
