27
Ø 6 mm
HEIGHT ADJUSTMENT OF STOVE
The Scan 68 has four adjustment screws under the stove.
Use the adjustment screws and the adjustment key (Accessories)
to get the stove to stand straight and level.
If the floor plate is used, the stove must be adjusted so that the
plate can be placed under the front of the stove.
NOTICE: It is very important that the stove is level to allow an
optimal function of the door. Please note that once mounted
the stove can no longer be adjusted!
CONNECTING PIECE
The stove is prepared from the factory for top
outlet.
TOP OUTLET REAR OUTLET
Ajustment key
