5
TECHNICAL DATA AND DIMENSIONS
Materials
Steel plate
Cast iron
Galvanised sheet
Vermicolite
Surface treatment Senotherm
Max. wood length ca. 33 cm
Weight Scan 68-1/2/7/8 ca. 98 kg
Weight Scan 68-3/4/9/10 ca. 105 kg
Weight Scan 68-5/6/11/12 ca. 107 kg
Weight Scan 68-13/14 ca. 110 kg
Weight Scan 68-13/14 LB ca. 100 kg
Weight Scan 68-15/16 ca. 190 kg
Weight Scan 68-15/16 LB ca. 170 kg
Connecting piece internal diameter 144 mm
Connecting piece external diameter 148 mm
Approval type Intermittent fuelling*
Intermittent operation in this context means normal use
of a wood-burning stove. In other words, you should let
the fire die down until only the embers are left before
refueling.
This stove is produced in accordance with type approval
for the product, which also covers the product’s Assembly
and Instruction Manual.
The Declaration of Performance (DoP) is available from
www.scan.dk
*
TECHNICAL DATA
INSTALLATION
¬ The house owner is responsible for ensuring that installation and assembly are in accordance with national and local
building regulations as well as the information provided in this Assembly and Instruction Manual.
¬ When you install any kind of fireplace or stove, you must inform the local building and housing authorities. In addition
you are obliged to have the installation inspected and approved by a local chimney sweep prior to commissioning.
¬ To ensure best-possible functionality and safety for your installation, we advise you to call a professional fitter. Your Scan
Dealer will be able to recommend a qualified fitter in your area. For information on Scan Dealers, please go to www.scan.dk.
SAFETY
Any changes made to the product by the dealer, fitter or user could result in the product and safety functions not functioning as
intended. The same applies to the fitting of accessories or extra equipment not supplied by Scan A/S. This could also be the case
if parts that are necessary for the operation and safety of the stove are dismantled or removed.
Test in compliance with EN 13240
CO Emission at 13% O
2
0,04 %
CO
Emission at 13% O
2
556 mg/Nm
3
Dust @ 13% O
2
14 mg/Nm
3
No
x
@ 13% O
2
85 mg/Nm
3
Efficiency 80 %
Energy efficiency index 107
Energy efficiency class A+
Nominel output 5,5 kW
Chimney temperature EN 13240 265 °C
Amount of smoke 5,3 g/sek
Sub-pressure EN 13240 12 Pa
Recommended sub-pressure in
connecting piece
17 Pa
Required combustion air supply 16,2 m
3
/h
Fuel Wood
Fuel consumption 1,6 kg/h
Amount of fuel 1,4 kg
Test in compliance with EN 13240
in smoke restricted areas
CO Emission at 13% O
2
0,06 %
CO
Emission at 13% O
2
785 mg/Nm
3
Dust @ 13% O
2
12 mg/Nm
3
No
x
@ 13% O
2
91 mg/Nm
3
Efficiency 79 %
Energy efficiency index 105,6
Energy efficiency class A
Nominel output 5 kW
Chimney temperature EN 13240 248 °C
