Lubrication system
OPM 320 en-GB 25
© Scania CV AB 2019, Sweden
Checking the oil level
Leave the engine off for at least 7 minutes before
you check the oil level.
1. Remove the oil dipstick and check the oil
level. The correct level is between the mini-
mum and maximum marks on the oil dip-
stick.
2. Top up with more oil via the oil filler if the
oil level is at or below the minimum mark.
For information on the correct oil grade, see the
section Oil grade
.
Maximum angles of inclina-
tion during operation
The illustration shows the maximum permissible
angles of inclination during operation.
1
2
375 553
1. Oil dipstick
2. Oil filler
