#SC 40RT 06 – 101027Page 34 of 44
Spare Part List SC 40RT
Pos. Part No. Qty.
Description
111a 30316-38 (1) Turbine Sleeve Acc. to order
111b 30319-37 (1) Flow Washer Acc. to order
112 104737 1 Screw
113 30219 1 Top Nut
114 802115 1 Washer
117 109275 1 O-ring
119 104758 4 Screw
120 30270 1 Cofferdam Plug
121 105095 1 Screw
122 105926 4 Nut
123 106148 4 Washer
124 120266 4 Pin Bolt
125 109285 1 O-ring
126 802131-xxx 1 Main Pipe with Flange
Acc. to order
127 104430 2 Screw
128 802127 1 Bearing Lower
129 106576 1 Splitpin
130 70037 1 Thrust Bearing
131 70036 2 Teflon Bearing
133 30111-xx 1 Inlet Housing
Acc. to order
134 70066 1 Strainer
135 70098 1 Expansion Ring
136 20005-x 1 Adjusting Sleeve Assembly
Acc. to order
137 109263 1 O-ring
138 20026 1 Nut
139 20025 1 Cup
143 802121-25 1 Nozzle Housing (2 Nozzles)
802141-25 (1) Nozzle Housing (4 Nozzles) Optional
145 70011 2 (4) Nut
146 50158 4 (8) Flow Guide
147 50156-100-L 2 (4) Nozzle Tube (Ø6-11 mm)
50156-150-L 2 (4) Nozzle Tube (Ø12-16 mm)
148 105087 2 (4) Bolt
149 50155-xx 2 (4) Nozzle (“-xx” is outlet diameter)
