#SC 40RT 06 – 101027 Page 7 of 44
4. Technical Data
4.1. Specifications
Approx weight
Machine, L=1 m : 38 kg (84 lb)
Per additional meter of mainpipe : 10 kg (22 lb)
Drive unit : 12 kg (26 lb) (composite 5 kg / 11 lb)
Material
Inlet housing and mainpipe : AISI 316L / SS2348 / WST 1.4404
Other parts : Makers’ standard
Service space : Min 350 mm radius from centre
of deck flange for handling and
service.
Rotation speed : 1-2 rpm (might differ with climate,
in cold climate the machine might
rotate slower)
Flow : 7-55 m3/h (30-240 USgpm)
Inlet pressure : 0,6-1,2 MPa (6-12 Bar, 85-175 psi)
Recommended pressure : 0,8 MPa (8 Bar, 115 psi)
Max working temperature : 95ºC (200ºF)
