16. Basic Settings
This lists serves as guidance for ordering spare parts depending on the number
and size of the nozzles on the machine. This list may be changed without prior
notice.
Nozzle size 2 x Ø6 mm
Pos. Part No. Qty. Description
110 21013-28 1 Turbine T2 Ø28
111 30024-28 1 Turbine Cone Ø28
136 20005-1 1 Adjusting Sleeve Assembly
143 802121-25 1 Nozzle Housing 2N
145 70011 2 Nut
146 50158 4 Flow Guide
147 50156-100-L 2 Nozzle Tube
148 105087 2 Bolt
149 50155-06 2 Nozzle Ø6 mm
Nozzle size 2 x Ø7 mm
Pos. Part No. Qty. Description
110 21013-38 1 Turbine T2 Ø38
111 30024-38 1 Turbine Cone Ø38
136 20005-1 1 Adjusting Sleeve Assembly
143 802121-25 1 Nozzle Housing 2N
145 70011 2 Nut
146 50158 4 Flow Guide
147 50156-100-L 2 Nozzle Tube
148 105087 2 Bolt
149 50155-07 2 Nozzle Ø7 mm
