Scanjet SC 40RT - Nozzle Size 2 x Ø8 mm; Nozzle Size 2 x Ø9 mm; Nozzle Size 2 x Ø10 mm

#SC 40RT 06 – 101027 Page 37 of 44
Nozzle size 2 x Ø8 mm
Pos. Part No. Qty. Description
110 21013-42 1 Turbine T2 Ø42
111 30024-42 1 Turbine Cone Ø42
136 20005-1 1 Adjusting Sleeve Assembly
143 802121-25 1 Nozzle Housing 2N
145 70011 2 Nut
146 50158 4 Flow Guide
147 50156-100-L 2 Nozzle Tube
148 105087 2 Bolt
149 50155-08 2 Nozzle Ø8 mm
Nozzle size 2 x Ø9 mm
Pos. Part No. Qty. Description
110 20013-35 1 Turbine T1 Ø35
111 30024-35 1 Turbine Cone Ø35
136 20005-1 1 Adjusting Sleeve Assembly
143 802121-25 1 Nozzle Housing 2N
145 70011 2 Nut
146 50158 4 Flow Guide
147 50156-100-L 2 Nozzle Tube
148 105087 2 Bolt
149 50155-09 2 Nozzle Ø9 mm
Nozzle size 2 x Ø10 mm
Pos. Part No. Qty. Description
110 20013-38 1 Turbine T1 Ø38
111 30024-38 1 Turbine Cone Ø38
136 20005-1 1 Adjusting Sleeve Assembly
143 802121-25 1 Nozzle Housing 2N
145 70011 2 Nut
146 50158 4 Flow Guide
147 50156-100-L 2 Nozzle Tube
148 105087 2 Bolt
149 50155-10 2 Nozzle Ø10 mm
