Scanjet SC 40RT - Dimensions

#SC 40RT 06 – 101027Page 8 of 44
4.2. Dimensions
178,2
272,7
L = Machine Length
20
xxx
182
56 130
150
Min.
opening
(2 nozzles)
380
Optional 2" Ball Valve
Max. rotation
400
(Nozzles: 2 x
6-11 mm)
Max. rotation
492
(NozzlS: 2 x
12-16 mm)
240
Min. opening
(4 nozzles)
Max. rotation
357
(Nozzles: 4 x
6-12 mm)
178,2
272,7
Scale
1:7
