5. Performance Data
Performance data: The table below shows the flow and effective jet length
(radius) for each combination of inlet pressure and nozzle diameter. Other
nozzles and maximum jet length available upon request.
Supply pressure MPa (Bar)
0,6 (6) 0,8 (8) 1,0 (10) 1,2 (12)
Nozzle size
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
2 x Ø6mm 7 7 8,5 7 9,3 8 10 9
2 x Ø7mm 10 10 11 11 13 12 13,5 13
2 x Ø8mm 11,5 13 14 14 15,5 15 17 16
2 x Ø10mm 19 16 22 17 25 18 27 19
2 x Ø12mm 28 18 30 19 34 20 36 21
2 x Ø14mm 34 20 38 21 42 22 45,5 24
2 x Ø16mm 40 19 44 20 48 21 53 22
