Scanprobe Maxprobe - Maxprobe System Overview; Design and Application; Figure 1: Full Maxprobe System

Maxprobe User Manual
Version 2.0
22 November 2023
14
Maxprobe System Overview
Design and Application
The Maxprobe Pushrod system consists of the following components:
1. Maxprobe Camera Control Unit (CCU)
2. Maxprobe Coiler
3. Pushrod
4. 44mm Camera head
1.
2.
3.
4.
Figure 1: Full Maxprobe System
