8. Technical Data
Technical Specifications
Type
SB 30
SB 40
Drilling Capacity, mm
36
42
Drilling Depth, mm
150
150
Morse Taper
MT3
MT4
Column Diameter, mm
Ø 100
Ø 120
Table Working Surface
405x505
405 x 505
Max. weight on working table
250 kgs
250 kgs
Cross Table
300x600
300x600
T-Bolt Size
DIN 508 Str.
15,75x25x18 mm
DIN 508 Str.
15,75x25x18 mm
Base Dimension
440 x 590
445 x 720
Distance Spindle to Table, mm
920
920
Distance Spindle to Column, mm
285
350
Distance Spindle to Base, mm
1240
1300
RPM
75-3140
75 – 3140
Speed Numbers - Spindle
8
8
Speed Numbers - Motor
2
2
Motor, HP
1,5
2,0
Height, mm
1800
1800
Weight, kgs
200
295
Optional Accessories
The optional accessories depend on the model, as standard we have the following
optional accessories:
• Coolant System
• Automatic Feed
• Milling Table
• Reversing Pedal
• Machine Vice
• Drill Chuck
• Working Light
Furthermore, it is possible to obtain special accessories by contacting the
producer.
