28
Spare Parts
Visatron VN115/87 EMC
For more information:
https://www.epp.no/spare-parts/spare-part-for-visatron-vn-115-87/
Position:
Part name:
Part no.:
Position:
Part name:
Part no.:
1
Heating element
10671 | 270765
11
Screw R1/2” gasket
10209 | 365280
2
Measuring head
10601 | 10601R
12
Flexible bellow
10023 | 365193
3
Inspection cover
10798 | 270412
13
Upper suspension
10018 | 200211
4
Inspection cover gasket
10166 | 355336
14
Measuring head seal
10022 | 330482
5
Scavenging air filter circlip
10041 | 365198
15
Lower suspension
10019 | 200212
6
Fresh air filter/Scavenging air filter
10042 | 365197
16
Valve box gasket
10405 | 330721
7
Plug R1/4”
10083
17
Oil mist gasket
10206 | 360136
8
Plug R1/4” gasket
10082
18
Connection socket
10033
9
Connection casing
10202 |10202R
19
Base plate
10604 | 10604R
10
Screw R1/2”
10208
