Schaller Automation VN/87 EMC Series User Manual

37
Visatron VN2020
For more information:
https://www.epp.no/spare-parts/spare-parts-for-vn2020/
Position:
Part name:
Incl. in kit:
Position:
Part name:
Incl. in kit:
1
Inspection cover
155000 &
155001
9
Terminal box incl. measuring head cable
155000 &
100164
2
Inspection cover gasket
155000,
155001 &
100171
10
Base plate
155000
3
Measuring head
155000 &
155001
11
Mea. head gasket
155000 &
100171
4
Lithium battery
155000,
155001 &
100172
12
Flexible bellow
155000,
100163 &
100171
5
Fuse
155000,
155001 &
100173
13
Pressure regulator
155000 &
100168/100169
6
Connection casing
155000
14
Filter element
155000,
155005/366717
&
100168/100169
7
Connection casing gasket
155000 &
100171
15
Flexible scavenging hose system
155000
8
Ejector in-/output system
155000
16
Upper- & lower suspension
155000,
100163 &
100171
