Schaudt IT 96-A - Block Diagram;Connection Diagram

Instruction Man u al Instrument Panels IT 96-A, IT 96-2
14
Issued: 26.11.2007 830.636 BA / EN
E Block diagram/connection diagram
nc 12V check
at pump 2x flat pins 4.8x0.8
Full 1/2 1/4 3/4 Base nc
Base 3/4 1/4 1/2 Full
+ Starter battery nc 12V off 12V on
Lumberg MSFQ/0 9 x
Mains indicator + Leisure battery sensor
at electrobloc
Leisure battery negative sensor
Lumberg MSFQ/0 6 x at water tank Lumberg MSFQ/0 5 x at sewage tank
