www.scheppach.com
GB
|
27
8. Unpacking
• Open the packaging and carefully remove the device.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as well
as type and year of manufacture for your equipment.
m WARNING!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Assembly
WARNING
Always pull out the mains plug before carrying out ad-
justments on the device.
• Prior to commissioning, all covers and safety devices
must be mounted correctly.
• It must be possible for the sanding belt (13) and sand-
ing disc (4) to run freely.
• In case of previously machined wood, be aware of
any foreign objects, such as nails or screws, etc.
• Before pressing the on/o switch (5), make sure that
the sanding paper is correctly tted, and that moving
parts run smoothly.
9.1 Assembly (Fig. 1−4b)
• Mount the sanding table (7) and secure with the lock-
ing screw (8) (g. 2, 3). The sanding table (7) can be
innitely adjusted from 0 ° to 45 ° with the angle scale
(9) and the locking screw (8).
The adjustable transverse stop (6) ensures safe guid-
ance of the workpiece. Attention! It must be possible
for the sanding disc (4) to run freely. The distance be-
tween the grinding table (7) and the grinding wheel (4)
should be max. 2 mm.
7. Technical data
Motor 230 - 240 V~ / 50 Hz
Rated input 370 W
Dimensions L x W x H 460 x 360 x 280 mm
ø Disc 150 mm
RPM disc 2980 min
-1
Sanding belt size 915 x 100 mm
Sanding belt speed 7.5 m/s
Angle positioning 0° - 90°
Table size 225 x 160 mm
Table tilt 0° - 45°
Weight approx. 11.5 kg
Technical changes reserved!
Noise and vibration
m Warning:Noise can have serious eects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
WA
94 dB(A)
Sound pressure level L
pA
81 dB(A)
Uncertainty K
WA/pA
3 dB(A)
The specied total vibration value and the specied
noise emission value have been measured in accord-
ance with a standardised test procedure and can be
used to compare one power tool with another.
The specied total vibration value and the specied
noise emission value can also be used for an initial esti-
mation of the exposure.
Note:
• The vibration and noise emission values can vary
from the specied values during the actual use of the
power tool, depending on the type and the manner
in which the power tool is used, and in particular the
type of workpiece being processed.
• It is necessary to dene safety measures to protect
the operator which are based on an estimate of vibra-
tion exposure during the actual operating conditions
(for this, all parts of the operating cycle have to be
considered, e.g. times during which the power tool is
switched o and times during which it is switched on
but runs in no-load mode).
