Scheppach CSP41 User Manual

www.scheppach.com
34
|
GB
Explanation of symbols
The use of symbols in this manual is intended to draw your attention to possible risks. The safety symbols and the
explanations that accompany them must be perfectly understood. The warnings in themselves do not remove the risks
and cannot replace correct actions for preventing accidents.
Read, understand and follow all warnings
Warning! Chance of kickback (kickback). Beware of a check of the chain saw and avoid
contact with the tip of the bar.
Do not use the device with one hand
Use the device with both hands.
Always wear safety glasses, hearing protection and a safety helmet
Read the complete user guide before using the appliance
Wear security and anti-vibration gloves when you use the device
Always wear non-skid safety shoes with cut protection when using this product
It is important you wear the protection clothing for feet, legs, hands and forearms.
Fuel ller cap
Filling hole for chain oil.
Choke knob
pressed - Choke disabled
pulled out - Choke activated
L
H
T
Adjustments for carburettor:
L Low Speed (It is not allowed to adjust)
H High Speed (It is not allowed to adjust)
T Idle Speed
Setting the chain tension:
White arrow: Loosen chain
Black arrow: Tighten chain

Scheppach CSP41 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Blade length	400 mm
Product color	Black, Red, White
Cutting length	375 mm
Automatic oiling	Yes
Engine displacement	41 cm³
Engine power	1.9 hp
Power source	Gasoline

Weight and Dimensions

Width	260 mm
Height	280 mm
Length	430 mm
Weight	6900 g
