Scheppach CSP41 User Manual

www.scheppach.com
GB
|
53
11. Storage
m CAUTION
Never put the equipment into storage for longer than
30 days without carrying out the following steps.
If you intend to store the equipment for longer than
30 days, it must be prepared accordingly. Otherwise
the fuel still remaining in the carburettor will evapo-
rate and leave a rubbery sediment. This can cause
problems when starting up the equipment and may
require expensive repairs.
1. Slowly remove the fuel tank cap to release any pres-
sure that may have formed in the tank. Carefully
empty the tank of fuel.
2. To remove the fuel from the carburettor, start the
engine and let it run until the equipment stops.
3. Leave the engine to cool (approx. 5 minutes).
4. Remove the spark plug. You will need the sup-
plied combined spark plug wrench/screwdriver.
5. Add one teaspoon of 2-stroke engine oil into the
combustion chamber.
6. Slowly pull the starter cord several times to apply
a layer of oil to all internal parts. Ret the spark
plug.
Putting the equipment back into operation
1. Remove the spark plug.
2. Quickly tug on the starter line to remove excess
oil from the combustion chamber.
3. Clean the spark plug and check that the electrode
gap is correct, or insert a new spark plug with the
correct electrode gap.
4. Prepare the equipment for operation.
5. Fill the fuel tank with the relevant mixture of fuel and oil.
6. Top up the chain oil in the chain oil tank.
12. Transportation
To transport the saw, empty the petrol tank. Remove
coarse dirt from the saw with a bust or a hand sweep
13. Disposal and recycling
Notes for packaging
The packaging materials are recy-
clable. Please dispose of packaging
in an environmentally friendly man-
ner.
General Chain saw
Saw chain
Chain brake
Guide bar
Clean exterior, check for damage. In case of damage have
repaired by a qualied service center immediately
Sharpen regulary, replace in good time
Have inspected regularly at an authorized service center
Turn over to ensure even wear of bearing surfaces
Replace in good time
Before each start Saw chain
Guide bar
Chain lubrication
Chain brake
OFF switch, Safety locking
button, Throttle lever
Fuel/ oil tank cup
Inspect for damage and sharpness
Check chain tension
Check for damage
Functional check
Functional check
Functional check
Check for tightness and leckage
Every day Air lter
Guide bar
Guide bar support
Idle speed
Clean
Check for damage, clean oil intake bore
Clean, in particular the oil guide groove
Check (chain must not run)
Every week Fan housing
Cylinder space
Spark plug
Mu󰀪er
Spark arrester screen
Chain catch sleeve
Screws and nuts
Clean to ensure proper air cooling
Clean
Check and replace if necessary
Check tightness of mounting
Clean
Check for damage, replace if necessary.
Check their condition and that they are rmly secured.
Every 3 months Fuel lter
Fuel, oil tank
Replace
Clean
Storage Chain saw
Guide bar/ chain
Fuel, oil tank
Carburretor
Clean exterior, check for damage. In case of damage, have
repaired by a qualied service center immediately
Demount, clean and oil slightly
Clean the guide groove of the guide bar
Empty and clean
Run empty

Scheppach CSP41 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Blade length	400 mm
Product color	Black, Red, White
Cutting length	375 mm
Automatic oiling	Yes
Engine displacement	41 cm³
Engine power	1.9 hp
Power source	Gasoline

Weight and Dimensions

Width	260 mm
Height	280 mm
Length	430 mm
Weight	6900 g
