www.scheppach.com
GB
|
27
Splitting
• Place the log on the table, hold it with both handles,
press the handles down. As soon as the splitting
knife enters the wood, push the handles down and
to the outside at the same time. This prevents the
wood from putting pressure on the holder plates.
• Only split straight cut logs.
• Split the logs in vertical position.
• Never split in horizontal position or across.
• Wear protective gloves when splitting.
Attention! The lateral tray tables may not be used as
splitting support or splitting table.
• Move the splitting knife to the lower position.
• Release one operating arm.
• Switch the machine o and pull the power plug.
• Close the venting cap.
• Observe the general maintenance instructions.
11. Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the appli-
cable VDE and DIN provisions.
The customer‘s mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
• The product meets the requirements of
EN 61000-3-11 and is subject to special connection
conditions. This means that use of the product at any
freely selectable connection point is not allowed.
• Given unfavourable conditions in the power supply
the product can cause the voltage to uctuate tem-
porarily.
• The product is intended solely for use at connection
points that
a) do not exceed a maximum permitted supply im-
pedance “Z” (Zmax = 0,354 Ω (230V) / 1,043 Ω
(400V)), or
b) have a continuous current-carrying capacity of
the mains of at least 100 A per phase.
• As the user, you are required to ensure, in consulta-
tion with your electric power company if necessary,
that the connection point at which you wish to oper-
ate the product meets one of the two requirements,
a) or b), named above.
Action: Result:
Push both handles
towards below.
Splitting knife goes down
to approx. 10 cm above the
table.
Let one handle loose,
then the other.
Splitting knife stops in the
desired position.
Let both handles
loose.
Splitting knife returns to
upper position.
Before working with the log splitter, vent the hydraulic
system.
• Release the venting cap 14 by a few revolutions so
the air can escape from the oil tank.
• Leave the cap open during the operation.
• Before you move the log splitter, close the cap again
in order not to lose any oil.
If the hydraulic system is not vented, the enclosed air
will damage the gaskets and with it the complete log
splitter.
Lower splitting knife position about 10 cm above table.
• Move splitting knife to the desired position
• Release one operating arm
• Switch motor o
• Release the second operating arm
• Undo the star grip screw (10a)
• Push the stroke set rod (8) to the top until it is
stopped by the spring
• Tighten the star grip screw (10a) again.
• Switch motor on
• Check upper position
Press the green button for switching on.
Press the red button for switching o.
Note: Check the function of the ON/OFF unit before
every use by switching on and o once.
In case of current failure, inadvertent pulling of the
plug, or a defective fuse, the machine is switched o
automatically.
For switching on again, press anew the green button
of the switch unit.
