34
|
GB
• Before you connect the equipment to the power
supply make sure the data on the rating plate are
dentical to the mains data.
• Connect the machine to a properly installed pro-
tective contact socket, with at least 16A circuit
breaker.
8. Attachment
Important. Pull out the power plug before carry-
ing out any maintenance, resetting or assembly
work on the circular saw!
equal parts.
Note: If compounds with a bolt (round head / or hexa-
gon), hex nuts and washers are backed up, the wash-
Insert screws each from outside to inside. Secure
connections with nuts on the inside.
Note: Tighten the nuts and bolts during assembly
only to the extent that they can not fall down.
-
8.1 Frame assembly, Fig. 5-7
1. Fix the four legs (17) with the bolts (g) and nuts (h)
to the struts (20+21).
m Warning!
them to the table!
Ensure that markings A and B are always oppo-
site each other.
2.
the bolts (g) and nuts (h) (Fig. 5).
3. Now place the rubber feet (22) on the legs (Fig. 6).
4. -
ing the hexagon head bolts and the nuts in the
corners (Fig. 7).
5. Afterwards, tighten all bolts and nuts to the frame.
8.2 Hand wheel assembly, Fig. 8
1. Place the washer (e) on the bolt (a).
2. Then place the bolt on the handle (b) and the
washer (c) on the bolt.
3. Fix the whole assembly to the hand wheel (8) and
secure it with the hex-nut (d).
8.3 Riving knife set-up (Fig. 9-11)
m Warning! Disconnect the mains cable!
The set-up of the riving knife (4) must be checked
before each use.
1. Set the saw blade (5) to the max. cutting depth,
put it in the 0° position and lock it. .
2. Remove the table insert (6) (Fig. 9)
m Warning! For transport reasons, the riving
6. Technical data
AC motor 220-240 V~ 50Hz
performance 2000 Watt
operating mode S6 20%*
Idle speed 4800 min
-1
Hard-metal blade ø 255 x ø 30 x 2,8 mm
Number of teeth 60
Thickness riving knife 2,5 mm
table size 565 x 565 (675) mm
Cutting height max.
90°
80 mm
Cutting height max.
45°
50 mm
height adjustment 0 - 80 mm
saw blade swivel 0 - 45°
suction port ø 35 mm
weight 28 kg
* operating mode S6 20%: Continuous opera-
tion with intermittent loading (playing time 10
min). Engine protection of to hot warming up:
It´s allowed to run the engine with nominal pow-
er maximum 20% of playing time. After this the
machine must run 80% of playing time steadily
without load.
Noise values
The total noise values determined in accordance
with EN 62841.
sound pressure level L
pA
92,6 dB(A)
uncertainty K
pA
3 dB
sound power level L
WA
105,6 dB(A)
uncertainty K
WA
3 dB
Wear hearing protection.
Total vibration values (vector sum - three directions)
determined in accordance with EN 62841.
7. Before starting the equipment
• The equipment must be set up where it can stand
securely, i.e. it should be bolted to a workbench, a uni-
versal base frame or similar.
•
before the equipment is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails or
screws, etc.
• Before you press the ON/OFF switch check that the saw
