knife (4) was xed in the lower position before
initial commissioning. Only work with the ma-
chine if the riving knife (4) is in the upper po-
sition. Fitting the riving knife (4) in the upper
position is as follows:
3. Loosen the locking handle (23) and push the riv-
ing knife (4) in the upper position (Fig. 10).
4. The gap between the saw blade (5) and the riving
knife (4) should be a maximum of 5 mm (Fig. 11).
5. -
ble insert (6).
8.4 Saw blade guard assembly (Fig. 12)
1. Place the saw blade guard (2) on the riving
knife (4) from above so that the screw (24) is
Attention: Press the quick locking button (A) in
order to place the saw blade guard (2) on the riv-
ing knife (4).
2. Do not tighten the bolt (24) too much; the saw
blade guard (2) must be able to move freely.
3. Place the extraction hose (3) on the extraction
adapter on the rear of the machine and on the ex-
traction nozzle of the saw blade guard (2).
4. Disassembly takes place in reverse order.
Warning!
Before starting to saw, lower the saw blade
guard (2) on to the work piece.
8.5 Saw blade assembly/replacement
(Fig. 9, 12, 13)
1. Warning! Disconnect the mains supply and wear
safety gloves.
2. Disassemble the saw blade guard (2) (Fig. 12).
3. Remove the table insert (6) (Fig. 9).
4. Loosen the nut by placing the open-ended spanner
(f) on the nut and countering with another open-end-
5. Warning! Turn the nut in the rotational direction of
the saw blade.
6.
movement.
7.
8. Insert the new saw blade in reverse order and tighten
it.
Warning! Observe the rotational direction; the
teeth have to point in the direction of rotation,
i.e. forwards.
9. Attach the table insert (6) and the saw blade guard
(2) again and set them.
10. Before working with the saw again, check the func-
tionality of the guards.
9. Using the saw
9.1 On/O switch (Fig. 14)
- The saw can be switched on by pressing the green
pushbutton (11) „I“.
- The red pushbutton (11) „0“ has to be pressed to
9.2 Cutting depth (Fig. 14)
Turn the round handle (8) to set the blade to the required
cutting depth.
- Turn anti-clockwise: larger cutting depth
- Turn clockwise: smaller cutting depth
After each new adjustment it is advisable to carry out a
trial cut in order to check the set dimensions.
9.3 Setting the angle (Fig. 14)
With the table saw you can make diagonal cuts to the left
oriented to the stop bar from 0 ° to 45 °.
m Check before each cut, that between the stop bar (e),
cross-stop (13) and the saw blade (5) a collision is not
possible.
-
- Set the required angle on the scale.
-
position.
9.4 Working with the rip fence
9.4.1 Setting the fence height (Fig. 15)
- The fence rail (25) of the rip fence (7) has two guiding
- Depending on the thickness of the material to be cut,
the higher side of the fence rail (25) has to be used
for thick material (work piece thickness above 25 mm)
and the lower side of the fence rail for thin material
(work piece thickness below 25 mm).
- For the adjustment, loosen the bolts on the side of the
rip fence (7) and push the fence rail (25) on the guide,
depending on the required position.
- Tighten the bolts again.
9.4.2 Rip fence assembly (Fig. 16)
- Fix the rip fence (7) by placing it at the back and pulling
the locking lever (23) down.
- For disassembly, pull the locking lever up and remove
the rip fence (7).
- The locking force of the rip fence can be set with the
rear knurled nut.
9.4.3 Setting the cutting width (Fig. 17)
- The rip fence (7) must be used for lengthwise cutting
of wood.
