16. Troubleshooting
Fault Possible causes Action
Blade dissolves after
󰀨
To slightly tightened fastening nut Tighten the right hand thread nut
Engine will not start Failure mains fuse Check mains fuse
Defective extension cable Replace extension cord
Connections on motor or switch not in order Repair by electrical specialist
Motor or switch faulty Repair by electrical specialist
Motor wrong direction
of rotation
Capacitor faulty Repair by electrical specialist
Wrong connection 
electrician
Motor will not work, the
fuse is active
Cross section of the extension cable is not
󰀩
See „Electrical connection“
Overload by a blunt saw blade Change saw blade
Fire marks on the
cutting surface
Blunt saw blade Sharpen or change saw blade
Wrong saw blade Change saw blade

Scheppach HS105 Specifications

General

Product color	Blue, White
Built-in light	No
Country of origin	Germany
Suitable for materials	Wood
Saw blade included	Yes
Input power	2000 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Blade diameter	255 mm
Number of teeth	60
Idle speed (max)	7000 RPM
Bevel capacity (max)	45 °
Cutting depth (45º)	50 mm
Cutting depth (90º)	80 mm

Weight and Dimensions

Depth	760 mm
Width	690 mm
Height	380 mm
Weight	30500 g
