35
* Operating mode S6 40%: Continuous duty with in-
termittent loading (operating time 10 min.). In order
avoid impermissible overheating of the motor, the
motor should be driven for only 40% of the operating
time with the stipulated nominal power and must then
continue to run with no load for the remaining 60% of
the operating time.
Noise
The total noise values were de-
termined in accordance with
EN 62841.
Sound pressure level L
pA
93,5 dB(A)
Uncertainty K
pA
3 dB
Sound power level L
WA
106,5 dB(A)
Uncertainty K
WA
3 dB
Wear hearing protection.
The eects of noise can cause a loss of hearing. Total
vibration values (vector sum - three directions) deter-
mined in accordance with EN 62841.
NOTE: The specied device emissions values have
been measured in accordance with a standardised
test procedure and can be used for comparison of
one electric tool with another.
The specied device emissions values can also be
used for an initial estimation of the load.
m WARNING: The noise emission values can vary
from the specied values during the actual use of the
electric tool, depending on the type and the manner
in which the electric tool is used, and in particular
the type of workpiece being processed. Implement
measures to protect against noise nuisance. In doing
so, take into account the complete working process,
including the times when the electric tool is working
without load or switched o. Suitable measures in-
clude regular maintenance and care of the electric
tool and the insertion tools, regular breaks as well as
proper planning of the working process.
8. Before starting the equipment
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
m DANGER
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, lm and small parts! There is a risk of
swallowing and suocation!
• The equipment must be securely installed, i.e. bolt-
ed down on a workbench, base frame or similar.
Use the holes on the inner side of the frame legs
for this.
• All covers and safety devices have to be properly
tted before the equipment is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws, etc.
• Before you press the On/O switch check that the
saw blade is tted correctly. Moving parts must run
smoothly.
• Before you connect the equipment to the power
supply make sure the data on the rating plate are
identical to the mains data.
• Connect the equipment to a properly installed pro-
tective contact socket, with at least 16 A circuit
breaker.
9. Assembly
m WARNING: Danger of injury!
Improper installation of the circular table saw may re-
sult in serious injury.
Before commissioning, properly and completely in-
stall the circular table saw, including all covers and
safety devices.
Never plug the mains plug into the power socket be-
fore completing the installation.
If connections are secured with a hexagonal bolt, nut,
spring washer and washer, the washer and spring
washer must be tted under the hexagonal bolt. The
spring washer always lies directly on the (inner) hex-
agonal bolt or nut.
Hexagon screws must each be inserted from outside
inwards, and the connections must be secured from
the inside with nuts. During assembly nuts and screws
must only be tightened until hand-tight, so that they
cannot fall out. If you tighten the nuts and screws fully
before nal assembly, the circular table saw cannot
be erected in a correct and stable manner.
9.1 Assembling the frame and table width exten-
sion (g. 4-10)
1. Turn circular table saw upside down and place
on the oor.
