m WARNING! This electric tool generates an elec
pair active or passive medical implants under certain
conditions. In order to prevent the risk of serious or
deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operat
ing the electric tool.
Residual risks
The machine has been built according to the
state of the art and the recognised technical
safety requirements. However, individual residu-
al risks can arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
main.
• Residual risks can be minimised if the „safety in
structions“ and the „Proper use“ are observed
along with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
• Avoid accidental starting of the machine: the oper
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor
mance.
• Hands may never enter the processing zone when
the machine is in operation.
•
chine prior to any operations.
6. Technical data
Supply voltage
Power (W) 1200
Protection class II
Idle speed n
o
(min
) 5500
sions (mm)
ø 160 x ø 20 x 2.4
Number of teeth 24 (
bled)
Riving knife (Thickness) (mm) 2
max. 90° (mm) 55
max. 45° (mm) 45
Inclination steplessly
b) Adjust the riving knife as described in this in-
struction manual. Incorrect spacing, positioning
tive in preventing kickback.
c) Always use the riving knife except when
plunge cutting. Riving knife must be replaced
after plunge cutting. Riving knife causes interfer
ence during plunge cutting and can create kick
back.
d) For the riving knife to work, it must be en-
gaged in the workpiece. The riving knife is inef
fective in preventing kickback during short cuts.
e) Do not operate the saw if riving knife is bent.
Even a light interference can slow the closing rate
of a guard.
Additional safety instructions
• Never use abrasive wheels in the machine.
• Make sure that the riving knife is adjusted so that
the distance to the sprocket ring of the saw blade is
not more than 5 mm and that the sprocket ring does
not stick out more than 3 mm above the lower edge
of the riving knife.
• Make sure that the dust catching mechanism is cor
rectly installed, as is described in this manual.
• Wear breathing protection. Always wear ear protec
tion.
• Only those saw blades recommended in the manu
al should be used.
• Replace the saw blades as described in this man
ual.
• If the electrical cable of this tool is damaged it must
be replaced by the manufacturer or the customer
ist in order to avoid dangers.
• Only use the recommended saw blades which cor
• Only use the manufacturer’s original saw blades
with the number Ø 160 mm, 160 x 20 x 2.4.
• Do not use any saw blades which do not correspond
to the characteristics described in these operating
instructions. Saw blades may not be brought to a
stop by pressure on the machine from the side.
• Make sure that the saw blade is tightly assembled
and turns in the correct direction.
• Hold the equipment on the insulated handles, when
you undertake work in which the tool being used
could come into contact with hidden electrical
source can electrify the metal parts of the tool and
lead to an electrical shock.
