13. Troubleshooting
Warning: In the interests of operational safety, always switch off the saw and remove the mains plug before
carrying out maintenance work.
Fault Possible causes Action
Saw blades break Tension incorrectly set Set the correct tension
Load to great Feed the workpiece more slowly
Incorrect saw blade variety Use the correct saw blades
Workpiece not fed straight Avoid exerting pressure from the side
Motor does not function Mains Gable faulty Change faulty parts
Motor faulty Call customer service. Do not attempt
to repair the motor yourself as this
should be carried out by trained
personnel.
Vibration
NOTE: The saw vibrates slightly
when the motor is running in normal
operation.
Saw incorrectely installed Refer to the instructions given earlier in
this manual for information on installing
the saw
Unsuitable underlay The heavier the work bench is,the
less the vibration. A bench made from
ply wood always vibrates more than
one made from solid wood. Select the
work bench best suited to your working
conditions
The work bench is not screwed down
or is on the motor
Tighten the locking lever
The motor is not secured Securely screw the motor in place
Saw blade swings out
Holders not aligned straight
Holders not aligned Losen the screws with which the
holders are fastenedto the arm.
Align the holders so that they are
perpendicular to each other and
retighten the screws.
23 / 48
FR
IT
DE
GB

Scheppach sd1600v Specifications

General

Blade length	134 mm
Throat depth	406 mm
Product color	Black, Blue
Stroke height	50 mm
Idle speed (max)	1700 RPM
Idle speed (min)	500 RPM
Table tilt range	0 - 45 °
Maximum power	120 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	630 mm
Width	295 mm
Height	370 mm
Weight	12700 g
Table depth	415 mm
Table width	255 mm
