• The generator is suitable for 230 V~ a.c. appliances.
• Do not connect the generator to the household net-
work as this may result in damage to the generator
itself or to other electrical appliances in your home.
Note: Some electrical appliances (power jigsaws,
drills, etc.) may have a higher level of power con-
sumption when used in difcult conditions.
Switching off the engine
• Before you switch off the generator, allow it to run
briey with no consumers so that it can “cool down”
• Move the ON/OFF switch (5) to position “O” with the
key.
• Close the petrol cock
Important: The generator is equipped with an over-
load cut-out.
This shuts down the socket (7). You can reactivate the
socket (6) by pressing the overload cut-out (7).
Important! If this happens, reduce the electric
power you are taking from the generator or re-
move any defective connected appliances.
10. Cleaning
Caution!
Switch off the motor and pull the spark plug boot from
the spark plug before doing any cleaning and mainte-
nance work on the equipment.
We recommend that you clean the equipment imme-
diately after you use it.
Machine
• Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it with
compressed air at low pressure.
• We recommend that you clean the device immedi-
ately each time you have nished using it.
• Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep into
the device.
Air lter (Fig. 6)
• The air lter should be cleaned after every 30 hours
of operation.
• Remove the air lter cover (8).
• Remove the lter element (7a).
• Clean the lter element with soapy water, rinse with
clear water and leave to dry well before reinstalling.
• Assemble in reverse order
• Keep the cable length to the consumer as short as
possible.
Connecting to earth (Fig. 4)
The housing is allowed to be connected to earth in
order to discharge static electricity. To do this, con-
nect one end of a cable to the earth connection on the
generator and the other end to an external earth (for
example an earthing rod).
Before starting the equipment
• Check the fuel level and top it up if necessary
• Make sure that the generator has sufcient venti-
lation
• Make sure that the ignition cable is secured to the
spark plug
• Inspect the immediate vicinity of the generator
• Disconnect any electrical equipment which may al-
ready be connected to the generator
Important! Before using the appliance for the rst
time the tank must be lled with a petrol mixture in a
mixing ratio of 1:50 (1 part oil to 50 parts petrol). To
do so, use the measuring jug inside the tank (Fig. 10)
Shake the petrol mixture before lling into the tank.
Mixture 2- stroke - oil
Regular
unleaded Petrol
1:50
0,02 l 1l
0,04 l 2l
0,06 l 3l
0,08 l 4l
9. Initial operation
Starting the engine
• Before starting , ensure that no applicance has
been connected to the generator .
• Open the petrol cock (5a) by turning it down
• Move the ON/OFF switch (5) to position “I” with the
key.
• Move the choke lever (3) to position “START”.
• Start the engine with the reversing starter (4) by
pulling the handle forcefully. Return the reversing
starter gently and slowly to the original position by
hand. If the engine does not start, pull the handle
again.
• Note: when the motor is started for the very rst
time. It will require a number of attempts to start
until the fuel has travelled from the tank to the
motor.
• Push the choke lever (3) back again after the en-
gine has started. (RUN)
Important: This socket may be loaded continuously
(S1) with 650W and temporarily (S2) for a maximum
of 2 minutes with 700W.
